Iron Sputtering Targets (Fe)

Iron Sputtering Targets (Fe)
Material Type Iron
Symbol Fe
Atomic Weight 55.845
Atomic Number 26
Color/Appearance Lustrous, Metallic, Grayish Tinge
Thermal Conductivity 80 W/m.K
Melting Point (°C) 1,535
Coefficient of Thermal Expansion 11.8 x 10-6/K
Theoretical Density (g/cc) 7.86
Ferromagnetic Magnetic Material
Z Ratio 0.349
Sputter DC
Max Power Density*
(Watts/Square Inch)
50
Comments Attacks W. Films hard, smooth. Preheat gently to outgas.

General

Iron is a chemical element with symbol Fe (from Latin: ferrum) and atomic number 26. It is a metal in the first transition series. It is by mass the most common element on Earth, forming much of Earth's outer and inner core. It is the fourth most common element in the Earth's crust. Its abundance in rocky planets like Earth is due to its abundant production by fusion in high-mass stars, where it is the last element to be produced with release of energy before the violent collapse of a supernova, which scatters the iron into space.

Material Notes

Iron Sputtering Targets, Purity is 99.9%, 99.95%; Circular: Diameter <= 14inch, Thickness >= 1mm; Block: Length <= 32inch, Width <= 12inch, Thickness >= 1mm.



Other Information of Iron Sputtering Targets

Applications
Electronics
• Semiconductor
• Flat panel displays
Features
Competitive pricing
• High purity
• Grain refined, engineered microstructure
• Semiconductor grade

Manufacturing Process
Refining
  Three-layer electrolytic process
• Melting and casting
  Electrical resistance furnace - Semi-continuous casting
• Grain refinement
  Thermomechanical treatment
• Cleaning and final packaging - Cleaned for use in vacuum
  Protection from environmental contaminants
  Protection during shipment
Options
99.999% minimum purity
• Semiconductor grade aluminum alloys available
  Al/Si,Al/Cu,Al/Cu/Si
• Planar circular targets up to 18'' (457mm) diameter
• Planar tiles up to 48'' (1200mm) X 15.75'' (400mm) for larger target configurations
• Smaller sizes also available for R&D applications
• Sputtering target bonding service
