Zinc Evaporation Material (Zn)

Zinc Evaporation Material (Zn)
Zinc Evaporation Material (Zn)
Material Type Zinc
Symbol Zn
Atomic Weight 65.38
Atomic Number 30
Color/Appearance Bluish Pale Gray, Metallic
Thermal Conductivity 116 W/m.K
Melting Point (°C) 420
Coefficient of Thermal Expansion 30.2 x 10-6/K
Theoretical Density (g/cc) 7.14
Z Ratio 0.514
E-Beam Excellent
Thermal Evaporation Techniques Boat:  Mo, W, Ta
Coil:  W
Basket:  W
Crucible:  Al2O3, Q
E-Beam Crucible Liner Material Fabmate®, Graphite, Tungsten
Temp. (°C) for Given Vap. Press. (Torr) 10-8:  127
10-6:  177
10-4:  250
Comments Evaporates well under wide range of conditions.


Zinc is a chemical element with symbol Zn and atomic number 30. It is the first element in group 12 of the periodic table. In some respects zinc is chemically similar to magnesium: both elements exhibit only one normal oxidation state (+2), and the Zn2+ and Mg2+ ions are of similar size. Zinc is the 24th most abundant element in Earth's crust and has five stable isotopes. The most common zinc ore is sphalerite (zinc blende), a zinc sulfide mineral. The largest workable lodes are in Australia, Asia, and the United States. Zinc is refined by froth flotation of the ore, roasting, and final extraction using electricity (electrowinning).

Material Notes

AEM Deposition provides Zinc pellets, Zinc pieces, and Zinc powder for sale, purity is 99.99%, 99.995%.

Click for a downloadable datasheet on the Zinc Evaporation Material (Zn)
Can't find the downloadable datasheet you need? Click here to send email to get it.
Click here for answers to some of the most common questions we get asked.
