Molybdenum Carbide Sputtering Targets (Mo2C)
| Material Type | Molybdenum Carbide |
| Symbol | Mo2C |
| Melting Point (°C) | 2,687 |
| Theoretical Density (g/cc) | 8.9 |
| Z Ratio | **1.00 |
| Sputter | RF |
| Type of Bond | Indium, Elastomer |
| Comments | Evaporation of Mo(CO)6 yields Mo2C. |
Molybdenum Carbide Sputtering Targets
Molybdenum Carbide (MoC and Mo2C) is a tough refractory ceramic material, commercially used in tool bits for cutting tools. Molybdenum Carbide should be an alternative catalyst with high efficiency for hydrogen production.
Molybdenum Carbide Sputtering Targets Information
Molybdenum Carbide Sputtering Targets
Purity: 99.5%;
Circular: Diameter <= 14 inch, Thickness >= 1mm;
Block: Length <= 32 inch, Width <= 12 inch, Thickness >= 1mm.
Indium bonding is recommended for this material due to its characteristics not amenable to sputtering like brittleness and low thermal conductivity. This material has a low thermal conductivity and susceptible to thermal shock.
More Information on Molybdenum Carbide Sputtering Targets
Applications
• Chemical Vapor Deposition (CVD) • Optical |
Features• High purity• Custom sizes available |
Manufacturing Process• Manufacturing - Cold pressed - Sintered, Elastomer bonded to backing plate
• Cleaning and final packaging, Cleaned for use in vacuum, |
Options
• 99.5% minimum purity
• Smaller sizes also available for R&D applications
• Sputtering target bonding service
|
